Shimano crankbout octalink 105/lx/xt/alivio

Merk: ShimanoShimano groep: SHIMANOShimano groepscode: T4000Shimano modelcode: FCT4010Modeljaar: 2014Cranklengte: 175 mmVertanding: 44-32-22Aantal armen: 4-armAantal kettingbladen: TripleAantal versnellingen: 9Kettingbeschermer: Met kettingbeschermerKleur: ZwartBB as-lengte: 126mmBout-cirkel diameter: 100/64mm

Product Description The Shimano 105 BB-5500 bottom bracket has been working perfectly for a long time The 105 BB-5500 bottom bracket from Shimano is an Octalink bottom bracket with an 8-splined interface and a steel axle. The 109.5 mm versions are compatible with 2x cranks, the 118.5 mm versions with 3x cranks. Even though it has been around for a while, this bottom bracket still holds up. Specifications:Application:RoadSeries:105 5500Type:BSA, ITAShell Width:68 mm, 70 mmAxle Length:109.5 mm, 118.5 mmAxle Type:Octalink (Road)E-Type Compatibility:noChaincase Compatibility:noTechnical Information:Bearings:steelAxle Material:steelBottom Bracket Cup Material:aluminiumCompatibility:Octalink crank arms with eight-speed splines for shorter grooves (Octalink MTB)Features:8-splined interface of bottom bracket axle and crankTechnology:Octalink In Shimano's Octalink system, the bottom bracket and crank are connected by an 8-tooth contact surface. This provides greater rigidity and greater load ca…

Product Description The BB-ES51 bottom bracket from Shimano - Versatile The BB-ES51 is a versatile Shimano bottom bracket with Octalink construction and 8-speed gearing. It is compatible with older MTB cranks and the Tiagra FC-4401. Its axle is made of plated steel. Specifications:Application:All Mountain, CityType:BSAShell Width:68 mm, 73 mmAxle Length:113 mm, 118 mm, 121 mm, 126 mmAxle Type:Octalink (MTB)E-Type Compatibility:noChaincase Compatibility:noTechnical Information:Bearings:steelAxle Material:steelBottom Bracket Cup Material:composite (left), steel (right)Compatibility:Octalink crank arms with eight-speed splines for longer grooves (Octalink MTB) Recommended for: FD-M530FC-M540FC-M510FC-M470FC-M440Tiagra FC-4401 (113 mm)Tiagra FC-4404 (121 mm)Features:hollow constructionoversized bottom bracket axle: large 22 mm hollow axle increases strength and load capacity while reducing weightmulti-tooth connection between bottom bracket axle and crankssealed compact bearingsTechnology:…

Product Description Shimano BB-ES300-AK bottom bracket - Octalink, chain case compatible The Shimano BB-ES300-AK is an Octalink bottom bracket that is compatible with chain cases. Its 8-tooth contact surface increases the load capacity compared to a square model. A 1.8 mm spacer is included with the bottom bracket. Specifications:Application:All Mountain, Touring, CityType:BSAShell Width:68 mmAxle Length:121 mmAxle Type:Octalink (MTB)E-Type Compatibility:noChaincase Compatibility:yesTechnical Information:Bearings:steelAxle Material:steelBottom Bracket Cup Material:composite (left), steel (right)Compatibility:Octalink crank arms with eight-speed splines for longer grooves (Octalink MTB)compatible with chaincaseonly for FC-M521: with enclosed spacer also compatible without chain case Recommended for: FC-T521Features:hollow constructionTechnology:Octalink In Shimano's Octalink system, the bottom bracket and crank are connected by an 8-tooth contact surface. This provides greater rigidity …
