Visaton Vs-w170s/8 Woofer 17 cm (6.5" ) 8 Ohm
17 cm Woofer met gecoate conus en een elastische rubber rand.Technical Data: Rated power: 50 W Maximum power: 80 W Nominal impedance Z: 8 Ohm Frequency response: fu-8000 Hz (fu: Lower cut-off frequency depending on cabinet) . Mean sound pressure level: 86 dB (1 W/1 m) Maximum cone displacement: 20 mm Resonance frequency fs: 36 Hz Magnetic induction: 1, 0 T Magnetic flux: 314 µWb Height of front pole-plate: 4 mm Voice coil diameter: 25 mm Height of winding: 12, 5 mm Cutout diameter: 148 mm Net weight: 1, 1 kg D. C. resistance Rdc: 5, 9 Ohm Mechanical Q factor Qms: 2, 43 Electrical Q factor Qes: 0, 66 Total Q factor Qts: 0, 52 Equivalent volume Vas: 38 l Effective piston area Sd: 129 cm² Dynamically moved mass Mms: 13 g Force factor Bxl: 5, 4 T m Inductance of the voice coil L: 1, 2 mH. Recommended cabinets: 20 l (closed)20 l ; 1x BR 19. 24 (length 14 cm)30 l ; 1x BR 15. 34 (length 12 cm)50 l ; 1x BR 15. 34.
84,95
