TE Connectivity YDTS26W21-39SNV001 Ronde connector Package 1 stuk(s)

3-polige XLR plug.Nikkel behuizing en zilvere contacten.The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. TECHNICAL DATA. Product Connector: Type XLRGender: maleElectrical.Number of contacts: 3Contact resistance: ≤ 3 mInsulation resistance initial: > 2 GAfter damp heat test: > 1 GDielectric strength: 1500 V dcRated current: 16 AAWG: 2. 5 mm²/14 AWGCapacitance between contacts: ≤ 4 pFMechanical Lifetime: >1000 cyclesInsertion / withdrawal force: ≤ 20 NCable O. D. range: 3. 5 mm - 8. 0 mmMaterials.Shell: ZnAl4 Cu1, gal Ni over Cu platingInsert: PA 6. 6 30% GR (glass reinforced)Contacts: CuZn39 Pb3Contact surface: gal 2 µm AgStrain-relief clamp: POMAntikink bushing: PUREnvironmental Flammability: UL 94 HBStandard compliance: IEC 61076-2-103Protection class: IP 40Solderability: Complies with IEC 6…

EUROLITE DMX Cable 2x0.22 100m bkHigh-quality DMX cableAdheres to the DMX standard USITT DMX-512/1990/-AVery flexible cableElectric cable with good shieldingRobust versionFor building DMX controlled lighting systems, LED spotlights etc.OMNITRONIC XLR socket/plug set 3pin black housing 5xSet of ten XLR connectorsEach with 5 pieces per setPackage contents1 x plug (male)Weight:5,15 kgEUROLITE DMX Cable 2x0.22 100m bkCable construction:2 x 0,22 mm²Cable length:100 mImpedance:110 ohmsPlug A:1 x no connector/cable onlyPlug B:1 x no connector/cable onlyColor:BlackDimensions:Diameter: à 6 mmWeight:4,89 kgOMNITRONIC XLR socket/plug set 3pin black housing 5xConnector type:3-pin XLR (M); 3-pin XLR (F)Construction:Plug for cableConnections:Solder tailMaterial:MetalColor:BlackWeight:270 g

3-polige XLR-socket.Nikkel behuizing en zilvere contacten.The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. Product Connector Type: XLRGender: femaleElectrical Capacitance between contacts: ≤ 4 pFContact resistance: ≤ 3 mΩDielectric strength: 1, 5 kVdcInsulation resistance: > 2 GΩ (initial)Insulation resistance: > 1 GΩ (after damp heat test)Rated current per contact: 16 ARated voltage: 50 VMechanical Cable O. D.: 3. 5 - 8. 0 mmInsertion force: ≤ 20 NWithdrawal force: ≤ 20 NLifetime: > 1000 mating cyclesWire size: max. 2. 5 mm²Wire size: max. 14 AWGWiring: Solder contactsLocking device: Latch lockMaterial Boot: PolyuretanBushing: Polyamide (PA 6 15% GR)Contact plating: 2 µm AgContacts: Bronze (CuSn8)Insert: Polyamide (PA 6. 6 30 % GR)Locking element: Zinc diecast (ZnAl4 Cu1)Shell: Zinc diecast …

De Procab VCR526A/S is een professionele, afgeschermde CAT6A connector die perfect is voor high-speed netwerktoepassingen. De connector ondersteunt snelheden tot 10 Gigabit Ethernet en een bandbreedte tot 550 MHz. Hij is ontworpen voor gebruik met zowel massieve als gewikkelde kabels van 22 tot 26 AWG. De plug heeft soldeerloze bevestiging voor een snelle, eenvoudige installatie. De connector is compatibel met de EIA/TIA568 A en B normen en wordt geleverd met afsluitdopjes voor de kabelbeëindiging.

Met deze RockBoard S-Connector voor effectpedalen sluit je gemakkelijk jouw gitaareffecten aan op elkaar, zonder dat je daarbij een kabel hoeft te gebruiken. De S-connector is recht, waardoor je pedalen op dezelfde hoogte kunnen liggen.. De plug is voorzien van twee 6.3 mm TS mono jack-connectoren en heeft een zeer compacte behuizing van ca. 12 mm, waardoor je jouw effectpedalen tegen elkaar aan kan schuiven.

Met deze RockBoard S-Connector voor effectpedalen sluit je gemakkelijk jouw gitaareffecten aan op elkaar, zonder dat je daarbij een kabel hoeft te gebruiken. De S-connector is recht, waardoor je pedalen op dezelfde hoogte kunnen liggen.. De plug is voorzien van twee 6.3 mm TS mono jack-connectoren en heeft een zeer compacte behuizing van ca. 12 mm, waardoor je jouw effectpedalen tegen elkaar aan kan schuiven.

Universal 3-point truss system in lightweight constructionAluminum alloy for a classic high-tech lookFast, efficient and reliable assembly via quick lock conical connectorsAn extensive selection of lengths, circular and corner elements offers maximum flexibilitySpecial designs according to customer specifications on requestTrusspipe: 35 mmAny RAL color available on requestVarious versions availableMade in EuropeFor application areas such as: Theater; Trade fair and shop fitting; installation; stageTrusspipe:35 mm; 35 mm x 2 mmColor:Alu colored; any RAL color available on requestWeight:320 g

Universal 4-point truss system in lightweight constructionAluminum alloy for a classic high-tech lookFast, efficient and reliable assembly via quick lock conical connectorsAn extensive selection of lengths, circular and corner elements offers maximum flexibilitySpecial designs according to customer specifications on requestTrusspipe: 35 mmAny RAL color available on requestVarious versions availableMade in EuropeFor application areas such as: Shop fitting; theater; Trade fair and shop fitting; installation; stageTrusspipe:35 mm; 35 mm x 2 mmColor:Alu colored; any RAL color available on requestWeight:90 g

Universal 2-point truss system in lightweight constructionAluminum alloy for a classic high-tech lookFast, efficient and reliable assembly via quick lock conical connectorsAn extensive selection of lengths, circular and corner elements offers maximum flexibilitySpecial designs according to customer specifications on requestTrusspipe: 35 mmAny RAL color available on requestVarious versions availableMade in EuropeFor application areas such as: Theater; Trade fair and shop fitting; installation; stageTrusspipe:35 mm; 35 mm x 2 mmColor:Alu colored; any RAL color available on requestWeight:200 g

EUROLITE DMX Cable 2x0.22 100m bkHigh-quality DMX cableAdheres to the DMX standard USITT DMX-512/1990/-AVery flexible cableElectric cable with good shieldingRobust versionFor building DMX controlled lighting systems, LED spotlights etc.OMNITRONIC XLR plug 3-pin bk 10xHigh-quality metal versionDifferent plug/connector colors for clear distinction10 pieces per setOMNITRONIC XLR socket 3-pin bk 10xHigh-quality metal versionDifferent plug/connector colors for clear distinctionWith rubber sealing ring, strain relief and anti-kink grommet10 pieces per setWeight:6,04 kgEUROLITE DMX Cable 2x0.22 100m bkCable construction:2 x 0,22 mm²Cable length:100 mImpedance:110 ohmsPlug A:1 x no connector/cable onlyPlug B:1 x no connector/cable onlyColor:BlackDimensions:Diameter: à 6 mmWeight:4,89 kgOMNITRONIC XLR plug 3-pin bk 10xConnector type:3-pin XLR (M)Construction:Plug for cableMaterial:MetalColor:SilverWeight:280 gOMNITRONIC XLR socket 3-pin bk 10xConnector type:3-pin XLR (F)Construction:Plug for c…
