Neutrik NC3FXX-B XLR-connector Bus, recht Aantal polen: 3 Zwart 1 stuk(s)
3-polige XLR-socket.Zwarte metalen behuizing en vergulde contacten. The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief.TECHNICAL DATAProduct • Connector: Type XLR • Gender: female Electrical • Capacitance between contacts: ≤ 4 pF • Contact resistance: ≤ 3 mΩ • Dielectric strength: 1,5 kVdc • Insulation resistance: > 2 GΩ (initial) • Insulation resistance: > 1 GΩ (after damp heat test) • Rated current per contact: 16 A • Rated voltage: 50 V Mechanical • Cable O.D.: 3.5 - 8.0 mm • Insertion force: ≤ 20 N • Withdrawal force: ≤ 20 N • Lifetime: > 1000 mating cycles • Wire size: max. 2.5 mm² • Wire size: max. 14 AWG • Wiring: Solder contacts • Locking device: Latch lock Material • Boot: Polyuretan • Bushing: Polyamide (PA 6 15% GR) • Contact plating: 0.2 µm Au hard alloy over 2 µm Ni • Contacts: Bron…
7,99
