Neutrik NTR-NYS373-2 Connector Rca Male Metaal ZwartProfessionele cinch plug met vergulde contacten. Voorzien van trekontlasting en een gekleurde markeerring.9,95
Neutrik NTR-NYS373-0 Connector Rca Male Metaal ZwartProfessionele cinch plug met vergulde contacten. Voorzien van trekontlasting en een gekleurde markeerring.9,95
Neutrik NTR-NYS373-4 Composiet Video Connector Rca Male Male Metaal ZwartProfessionele cinch plug met vergulde contacten. Voorzien van trekontlasting en een gekleurde markeerring.9,95
Neutrik Ntr-nc3 fxx Connector Zilver3-polige XLR-socket.Nikkel behuizing en zilvere contacten.The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. Product Connector Type: XLRGender: femaleElectrical Capacitance between contacts: ≤ 4 pFContact resistance: ≤ 3 mΩDielectric strength: 1, 5 kVdcInsulation resistance: > 2 GΩ (initial)Insulation resistance: > 1 GΩ (after damp heat test)Rated current per contact: 16 ARated voltage: 50 VMechanical Cable O. D.: 3. 5 - 8. 0 mmInsertion force: ≤ 20 NWithdrawal force: ≤ 20 NLifetime: > 1000 mating cyclesWire size: max. 2. 5 mm²Wire size: max. 14 AWGWiring: Solder contactsLocking device: Latch lockMaterial Boot: PolyuretanBushing: Polyamide (PA 6 15% GR)Contact plating: 2 µm AgContacts: Bronze (CuSn8)Insert: Polyamide (PA 6. 6 30 % GR)Locking element: Zinc diecast (ZnAl4 Cu1)Shell: Zinc diecast …14,95
Neutrik Ntr-nc3 mxx Connector Zilver3-polige XLR plug.Nikkel behuizing en zilvere contacten.The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief. TECHNICAL DATA. Product Connector: Type XLRGender: maleElectrical.Number of contacts: 3Contact resistance: ≤ 3 mInsulation resistance initial: > 2 GAfter damp heat test: > 1 GDielectric strength: 1500 V dcRated current: 16 AAWG: 2. 5 mm²/14 AWGCapacitance between contacts: ≤ 4 pFMechanical Lifetime: >1000 cyclesInsertion / withdrawal force: ≤ 20 NCable O. D. range: 3. 5 mm - 8. 0 mmMaterials.Shell: ZnAl4 Cu1, gal Ni over Cu platingInsert: PA 6. 6 30% GR (glass reinforced)Contacts: CuZn39 Pb3Contact surface: gal 2 µm AgStrain-relief clamp: POMAntikink bushing: PUREnvironmental Flammability: UL 94 HBStandard compliance: IEC 61076-2-103Protection class: IP 40Solderability: Complies with IEC 6…11,95
Neutrik Ntr-nc4 mx Nl4 mx Connector4-delig XLR-kabeldeel, male. Nikkel behuizing en zilvere contacten.The "industry standard" XLR cable connector, easy to assemble with only 4 parts and no screws. Compact design with sturdy diecast shell, fibreglass reinforced hard plastic insert and chuck type strain relief for secure clamping of all cables. 4 pole male cable connector with Nickel housing and silver contacts.Features & Benefits.Rugged zinc diecast shell, long lasting and durableChuck type strain relief system for secure clamping of cablesBoot with rubber gland gives high protection against bending stressesColoured rings and boots available for coding and markingUL recognized components14,95
Neutrik NC3MXX-BAG Male XLR kabeldeel 3p zwartDe Neutrik NC3MXX-BAG is waarschijnlijk de bekendste male XLR plug ter wereld. Deze 3-pins uitvoering is een veelvoorkomende aansluiting en Neutrik is een topmerk op dit gebied. De NC3MXX-BAG is de zwarte uitvoering met zilveren contacten.4,-
Neutrik NC3MXX-BAG Male XLR kabeldeel 3p zwartDe Neutrik NC3MXX-BAG is waarschijnlijk de bekendste male XLR plug ter wereld. Deze 3-pins uitvoering is een veelvoorkomende aansluiting en Neutrik is een topmerk op dit gebied. De NC3MXX-BAG is de zwarte uitvoering met zilveren contacten.4,-
