Moza Racing AY210 Force Feedback YOKE
Precision Control, True-to-Life Flight
Designed for both general aviation and commercial airliners, the MOZA AY210 Yoke Base features proprietary MCLS¹ force feedback technology, delivering an authentic and immersive flying experience with unparalleled precision.
High-Strength Steel Construction
Built with high-strength steel, the AY210 Yoke ensures exceptional durability, rigidity, and a refined finish. This robust structure guarantees long-term stability, meeting the demands of professional flight simulation.
All-Aluminum Quick-Release Mechanism
Inspired by racing car technology, the quick-release mechanism allows for fast and effortless attachment or detachment from the flight base. This feature enables seamless switching between different yokes to suit various aircraft types.
Programmable Switch Panel for Advanced Control
The front panel features 13 fully customizable physical switches, configurable via MOZA Cockpit software. Users can assign functions such as lighting, telemetry, and long-press commands, enhancing the flight experience during takeoff, landing, and navigation.
150mm Travel Distance for Superior Control
With an extended 150mm range of motion, the AY210 Yoke delivers exceptional precision and responsiveness, making it ideal for professional-grade performance.
9Nm Torque and 210N Push Force
Roll Axis: Continuous 9Nm torque, providing detailed force feedback for realistic aircraft handling.
Pitch Axis: Peak push and pull force of 210N, simulating the dynamic resistance of real aircraft controls.
Full 180° Rotation for Realistic Handling
The ±90° roll axis accurately replicates the movement range of real aircraft controls, ensuring smooth and precise maneuvering for immersive flight experiences.
High Performance, Instant Response
Equipped with a 280MHz high-speed processor and a 15-bit high-resolution magnetic encoder, the AY210 delivers ultra-responsive inputs for both fine-tuned adjustments and aggressive maneuvers.
Compatible with Leading Flight Simulation Titles
The system supports built-in telemetry force feedback for major flight simulation games, including:
Microsoft Flight Simulator 2024
Microsoft Flight Simulator 2020
Microsoft Flight Simulator X (PC)
War Thunder (PC)
DCS World 2.9
Star Citizen
IL-2 Sturmovik: Great Battles
X-Plane 11 & 12
Versatile Mounting Options
Compatible with a variety of mounting methods:
Extensive Software Customization
MOZA Cockpit software enables users to fine-tune force feedback presets, lighting behavior, and button functions, ensuring a personalized and highly immersive experience.
Engineered for Durability
The AY210 Yoke undergoes millions of extreme stress and endurance tests, ensuring long-term performance with no structural or electronic failures.
Specifications
Dimensions: Composite
Housing Material: Aluminum Alloy
Weight: 8.0 kg
Motors: Dual high-performance servo motors
Max Pitch Force: 210N
Sustained Roll Torque: 9Nm
Travel Distance: 150mm
Compatible Yokes: All MOZA bases and most third-party bases
Power: 216W
Voltage: 110~220V AC → 36V DC
Chip Precision: 15-bit magnetic encoder
USB Refresh Rate: 1000Hz
Mounting Options: Desktop clamp (optional), suspended desktop clamp (optional), direct mounting on a simulator cockpit
Connection Ports: Power, USB, throttle, rudder pedals, panel, etc.
Emergency Stop Switch: Optional
Intelligent Telemetry Force Feedback: Supported (no plug-in required)
Native Force Feedback: Supported
Platform Support: PC
The MOZA Racing AY210 Force Feedback Yoke delivers a hyper-realistic flight experience with precision control, high-performance force feedback, and advanced customization-setting a new standard in flight simulation technology.
