LevelOne GVT-0302

Meer LevelOne
Meer LevelOne in Netwerkaccessoires

LevelOne GVT-0302

0
Add a 1000Base-ZX connection to LevelOne switchs with mini GBIC/SFP portsConnect switches up to 80km away with each otherTTL signal detect indicatorCompliant with IEEE802.3z Gigabit EthernetEasy to install and hot-swappableDifferential LVPECL input and outputSingle 3.3V power supplyDuplex LC connector- EAN: 4015867113622 - Vendorcode: GVT-0302 ...

Snel naar

  • Prijzen

    PrijzenProductomschrijvingProductspecificaties

    Verkopers met dit product

    Webshop
    Bezorging
    Prijs
    Megekko NL logo
    Megekko NL
    2 dagen
    gratis
    €62,95

    Anderen bekeken ook

    Digitus mini GBIC (SFP) Module
    Digitus mini GBIC (SFP) Module
    The DIGITUS mini GBIC (SFP) Transceiver Modules offer highest Quality and Reliability. Wether from Switch to Switch, Converter to Switch, Converter to Converter or any else application: The wide product range of DIGITUS Modules makes possible a flexible usage of the Fiber Technology. The Conformity to the MSA (Multi Source Agreement) Standard ensures a Compatibility to third party Manufacturers.- mini GBIC SFP (Small Form Factor Pluggable) Module- High quality and excellent reliability- 1.25 Gbps Maximum Data Rate- Compliant to IEEE 802.3z Gigabit Standard- Class 1 Laser product compliant with EN 60825-1- Easy Plug and Play Installation- MSA (Multi Source Agreement) compliant- Hot pluggable- Connector: 1x LC Duplex- 1000Base-SX - For Short Haul- Wavelength: 850nm- Transmission Power: Minimum -8 dBm, Maximum -3 dBm- Sensitivity Receiving Power: Minimum -20 dBm- For a Distance of up to 0.55km- Suitable for 50/125µm and 62.5/125µm Multimode Fiber Cables- Safe fast-locking mechanism- 3.3V …
    17,95
    LevelOne SFP-9221
    LevelOne SFP-9221
    1310nm FP LDMulti Data Rate: 125M to 1.25Gbps, NRZSingle +3.3V Power SupplyAC/AC Differential Electrical InterfaceRoHS Compliant and Lead-freeCompliant with Multi-Source Agreement (MSA) Small Form Factor Pluggable (SFP)Single LC ConnectorCompliance with specifications for IEEE802.3z Gigabit Ethernet at 1.25GbpsCompliance with ANSI specifications for Fiber Channel applications at 1.06bpsEye Safety Designed to meet LASER Class 1 comply with EN60825-1- EAN: 4015867154779 - Vendorcode: SFP-9221
    27,95
    LevelOne SFP-3001
    LevelOne SFP-3001
    850nm VCSELData Rate: 1.25GbpsSingle +3.3V Power SupplyRoHS Compliant and Lead-freeAC/AC Differential Electrical InterfaceCompliant with Multi-Source Agreement(MSA)Duplex LC ConnectorCompliance with specifications for IEEE 802.3z Gigabit Ethernet at 1.25GbpsCompliance with ANSI specifications for Fiber Channel applications at 1.06bpsNo configuration or installation software requiredEye Safety Designed to meet LASER Class 1 comply with EN60825-1- EAN: 4015867154663 - Vendorcode: SFP-3001
    22,95
    LevelOne USB-0503 Ethernet 1000Mbit/s netwerkkaart & -adapter
    LevelOne USB-0503 Ethernet 1000Mbit/s netwerkkaart & -adapter
    Level One USB-0503 Met de LevelOne USB-0503 USB Hub en Gigabit Ethernet Combo Adapter kunt u verbinding maken met internet via de USB-poort van uw laptop en tegelijkertijd andere USB-randapparatuur bedienen, zoals MP3-spelers, digitale cameras, printers of geheugensticks. De ideale oplossing voor MacBook of andere Windows-computers die een draadloos LAN hebben, maar geen eigen Ethernet-poort hebben, maar zijn uitgerust met een USB- of Thunderbolt-interface. Soms hebt u een LAN-verbinding nodig om gegevens over te dragen of toegang te krijgen tot gevoelige gegevens. De USB-0503 neemt deze taak over en bedient alles via de USB-poort. De USB-0503 is compatibel met USB 1: 0, 2: 0 en 3: 0 Hij volgt ook de Ethernet-normen 80 2: 3 / 3u en 80 2: 3ab, waarmee een Gigabit Ethernet-snelheid tot 1000 Mbit / s mogelijk is. Deze snelheid is geschikt voor alle snelle breedbandinternetverbindingen en voor snelle gegevensoverdrachten in het LAN. Dit maakt de USB-0503 de ideale keuze voor betrouwba…
    29,95
    TP-LINK Switch Gigabit TL-SG1024DE 24P Easy Smart
    TP-LINK Switch Gigabit TL-SG1024DE 24P Easy Smart
    What This Product DoesThe TL-SG1024DE 24-Port Gigabit Easy Smart switch is an ideal upgrade from an unmanaged switch, designed for Small and Medium Business networks that require simple network management. Network administrators can effectively monitor traffic via Port Mirroring, Loop Prevention and Cable Diagnostics features. To optimize traffic on your business network, TL-SG1024DE offers Port-based/802.1p/DSCP QoS1 to keep latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, the TL-SG1024DE can save up to 18% of power consumption, making it an eco-friendly solution for your business network. Effective ManagementTP-LINKs Gigabit Easy Smart switch, TL-SG1024DE offers network monitoring for users to observe traffic behavior. With Port Mirroring, Loop Prevention and Cable Diagnostics features, TL-SG1024DE …
    96,95
    Level One GEP-0821
    Level One GEP-0821
    - Complies with IEEE 802.3af, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab and IEEE 802.3x- 8 PoE ports support 15.4W power to PoE Powered Device- Provide safe and reliable power to WLAN Access Points or Network Cameras- Auto-detection and protection of non-standard Ethernet Terminals- Supports 10/100/1000Mbps Base-T applications- Auto-MDI/MDI-X detection on each RJ-45 port- Internal power supply- Compact design fits easily in WLAN Access- Total PoE power budget: 123.2WProduct OverviewThe LevelOne GEP-0821 is a high-performance 10/100/1000Mbps Gigabit Ethernet PoE Switch. Each PoE Port is powered up to 15.4W. The total PoE power budget is 123.2W. The switch automatically detects IEEE802.3af compliant powered devices and provides power and data over a single cable. Its an ideal solution for office and home users to utilize a combination of PoE and non-PoE devices.Advance Switching with PoE FunctionThe GEP-0821 offers advance switching and provide power to network devices using Ethernet cables.…
    299,-
    LevelOne KVM-1631
    LevelOne KVM-1631
    Control servers and computers either locally via control port or remotely via optional modules through the module expansion slot Features an expansion slot for flexible installation with optional module choicesFlexible auto-scan mode for flexible PC monitoringBuilt-in daisy chain port for cascading with KVM-0830/0831 or KVM-1630/1631 up to 8 unitsHigh video display quality up to 1920x1440 Support Windows, NetWare, Unix, Linux, Mac OS and Sun MicrosystemsWeb based User-interface- EAN: 4015867138083 - Vendorcode: KVM-1631
    689,-

    Klanten-reviews van LevelOne GVT-0302

    Er zijn nog geen beoordelingen voor dit productBen jij de eerste die een review plaatst?

    Meer over LevelOne GVT-0302

    Productomschrijving

    Add a 1000Base-ZX connection to LevelOne switchs with mini GBIC/SFP ports
    Connect switches up to 80km away with each other
    TTL signal detect indicator
    Compliant with IEEE802.3z Gigabit Ethernet
    Easy to install and hot-swappable
    Differential LVPECL input and output
    Single 3.3V power supply
    Duplex LC connector
    - EAN: 4015867113622
    - Vendorcode: GVT-0302

    Productspecificaties

    Artikelnummer(s)
    EAN
    4015867113622
    Brand
    LevelOne
    SKU
    GVT-0302
    Prestatie
    SFP transceiver type
    Vezel-optiek
    Maximale overdrachtssnelheid van gegevens
    1250 Mbit/s
    Soort aansluiting
    SFP
    Single-mode glasvezelkabel (SMF) ondersteund
    Ja
    Vezel-optische connector
    LC
    Vezelkabel diameters ondersteund
    9/125 µm
    SFP-zendernorm
    ZX
    Maximaal bereik
    80000 m
    Golflengte
    1550 nm
    Tx vermogen (max)
    5 dBmW
    Link budget
    23 dB
    Netwerkstandaard
    IEEE 802.3z
    Kenmerken
    Hot-plug ondersteuning
    Ja
    Compatibele producten
    GSW-2453 GVT-4000
    Energie
    Ingangsspanning
    3.5 V
    Maximaal voltage
    6 V
    Stroom (max.)
    0,3 A
    Certificaten
    Certificering
    Class 1 Laser: EN60825-1 FDA 21: 1040.10, 1040.11
    Eisen aan de omgeving
    Bedrijfstemperatuur (T-T)
    0 - 70 °C
    Relatieve vochtigheid in bedrijf (V-V)
    5 - 90 procent
    Gewicht en omvang
    Breedte
    55,5 mm
    Diepte
    13,5 mm
    Hoogte
    11,7 mm
    Inhoud van de verpakking
    Aantal per verpakking
    1 stuk(s)
    Verpakking
    Breedte verpakking
    153 mm
    Diepte verpakking
    51 mm
    Hoogte verpakking
    230 mm
    Gewicht verpakking
    180 g
    Logistieke gegevens
    Code geharmoniseerd systeem (HS)
    85369010
    Land van herkomst
    Taiwan
