Level One GEP-0821

Meer LevelOne
Meer LevelOne in Hubs & switches

Level One GEP-0821

0
- Complies with IEEE 802.3af, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab and IEEE 802.3x- 8 PoE ports support 15.4W power to PoE Powered Device- Provide safe and reliable power to WLAN Access Points or Network Cameras- Auto-detection and protection of non-standard Ethernet Terminals- Supports 10/100/1000Mbps Base-T applications- Auto-MDI/MDI-X detection...

Snel naar

  • Prijzen

    PrijzenProductomschrijvingProductspecificaties

    Verkopers met dit product

    Verkoper
    Bezorging
    Prijs
    Megekko NL logo
    Megekko NL
    3 dags
    gratis
    €299,-

    Anderen bekeken ook

    Edimax GP-103IT PoE adapter & injector 10 Gigabit Ethernet, 100 Gigabit Ethernet, Gigabit Ethernet
    Edimax GP-103IT PoE adapter & injector 10 Gigabit Ethernet, 100 Gigabit Ethernet, Gigabit Ethernet
    The Edimax GP-103IT is a Power over Ethernet (PoE) injector that not only delivers a cost-effective solution for power distribution, but also provides a seamless way of deployment on the existing LAN infrastructure. With the use of power injectors, DC power of up to 90W based on the IEEE 802.3bt standard and the data that comes from a non-PoE switch or router are merged together and then transmitted to the remote IEEE 802.3af/at/btcompliant products located without power outlet through the Ethernet cabling. Hence, the easy plug-and-play GP-103IT Gigabit PoE++ injector preserves your investment in hardware upgrade without the need for spending on extra PoE switches and deploying power cables.IEEE 802.3af/at/btPower over Ethernet StandardBecause of adding the capability of IEEE 802.3af/at/btPower over Ethernet (PoE) to a non-PoE Ethernet switch or router, the GP-103IT can directly be connected to any IEEE 802.3af/at/btend-nodes such as speed dome IP cameras, , Digital Signage, color touc…
    105,95
    Edimax ES-5104PH V2 Netwerk Schakelaar 10/100 Mbit
    Edimax ES-5104PH V2 Netwerk Schakelaar 10/100 Mbit
    The Edimax ES-5104PH V2 is a five port Fast Ethernet switch with four PoE+ Ports designed for use in home, small or medium sized network environments. With four DIP switches, PoE ports can be manually set with on/off control, extending PoE delivery distance up to 200 meters and port-based on/off control for VLAN and QoS is also supported. The switch easily connects and supplies power to PoE-enabled devices such as wireless access points, network cameras and IP phones as well as other Ethernet-enabled devices such as computers, printers or network attached storage (NAS). The compact size and fan-less design make the switch an ideal solution for expanding home and small business networks.Power over Ethernet (PoE+) Auto DetectionFeatures four IEEE 802.3at Power over Ethernet (PoE+) ports which supply up to 30 watts of electricity per port. It can convert standard 100?240V AC power into low?voltage 50 - 57V DC electricity to power IEEE 802.3at compliant network accessories via existing LAN…
    98,95
    Edimax GP-103IT Ieee 802.3bt Gigabit 90w Poe++ Injector
    Edimax GP-103IT Ieee 802.3bt Gigabit 90w Poe++ Injector
    The Edimax GP-103IT is a Power over Ethernet (PoE) injector that not only delivers a cost-effective solution for power distribution, but also provides a seamless way of deployment on the existing LAN infrastructure. With the use of power injectors, DC power of up to 90W based on the IEEE 802.3bt standard and the data that comes from a non-PoE switch or router are merged together and then transmitted to the remote IEEE 802.3af/at/btcompliant products located without power outlet through the Ethernet cabling. Hence, the easy plug-and-play GP-103IT Gigabit PoE++ injector preserves your investment in hardware upgrade without the need for spending on extra PoE switches and deploying power cables.IEEE 802.3af/at/btPower over Ethernet StandardBecause of adding the capability of IEEE 802.3af/at/btPower over Ethernet (PoE) to a non-PoE Ethernet switch or router, the GP-103IT can directly be connected to any IEEE 802.3af/at/btend-nodes such as speed dome IP cameras, , Digital Signage, color touc…
    199,95
    Zyxel Switch 5p 1000mb Gs-105b
    Zyxel Switch 5p 1000mb Gs-105b
    Optimized for Smooth VoIP and Data ExchangeThe ZyXEL GS-105 B v3 5-Port Desktop Gigabit Ethernet Switch connects network devices and the home network at blazing Gigabit speed. The newly designed QoS ports guarantee smooth transfer for bandwidthintensive applications such as VoIP and data communications.Compact, sturdy switch with alternative wall-mount designThe GS-105 B v3 fits any environment. Regardless of desktop or wallmount installation, its sturdy, compact design provides more flexibility for wired home networks.Fast, reliable wired connectivityWithout any manual configuration, the GS-105 B v3 can boost data transfer speed for connected network devices such as IP phones, network storages, PCs and laptops to the network at blazing-fast Gigabit speed.Optimized for smooth VoIP and data exchangeThe GS-105 B v3 has 3 QoS ports with an assigned high- and mediumpriority mechanism to enhance the stability of VoIP and data exchange. Just connect network devices such as IP phones, PCs, la…
    44,95
    Zyxel Switch 8p 1000mb Gs-108b
    Zyxel Switch 8p 1000mb Gs-108b
    Optimized for Smooth VoIP and Data ExchangeThe ZyXEL GS-108 B v3 8-Port Desktop Gigabit Ethernet Switch connects network devices and the home network at blazing Gigabit speed. The newly designed QoS ports guarantee smooth transfer for bandwidthintensive applications such as VoIP and data communications.Compact, sturdy switch with alternative wall-mount designThe GS-108 B v3 fits any environment. Regardless of desktop or wallmount installation, its sturdy, compact design provides more flexibility for wired home networks.Fast, reliable wired connectivityWithout any manual configuration, the GS-108 B v3 can boost data transfer speed for connected network devices such as IP phones, network storages, PCs and laptops to the network at blazing-fast Gigabit speed.Optimized for smooth VoIP and data exchangeThe GS-108 B v3 has 4 QoS ports with an assigned high- and mediumpriority mechanism to enhance the stability of VoIP and data exchange. Just connect network devices such as IP phones, PCs, la…
    55,95
    Edimax GS-1024 netwerk-switch Gigabit Ethernet (10/100/1000) Zwart
    Edimax GS-1024 netwerk-switch Gigabit Ethernet (10/100/1000) Zwart
    The GS-1024 is 24-Port Gigabit switch is designed to upgrade or expand the network with high-speed, enhanced performance while maintaining a compact form factor. It boasts outstanding performance and high efficiency, while its store and forward packet-switching technology and standard IEEE 802.11p QoSfeature offer improved traffic and reliable data transfer with priority of video and voice. It is ideal for network connectivity in the home, small office, small-and-Medium business and enterprise environments.The GS-1024 is designed with fanless, wall-mounted, rack-mounted and metal case and offers an easy plug-and-play, flexible-deployment, cost-effective, energy efficient solution for users looking to extend networks and fulfill their high bandwidth data transfer and streaming needs.Gigabit High-Speed NetworkWith Gigabit speed, the GS-1024 brings high-flexibility and high-bandwidth connectivity and delivers up to 2000Mbps of throughput per port at full-duplex mode to servers, workstatio…
    132,95
    Edimax GP-101ET Netwerk Switch Gigabit
    Edimax GP-101ET Netwerk Switch Gigabit
    Power over Ethernet (PoE) is typically limited to a range of 100 meters due to cable capacity. For longer-distance PoE networking though, the GP-101ET PoE+ Extender is the perfect accessory - increasing capacity up to another 100 meters (328 ft). Its a 1-Port Gigabit PoE Extender with plug and play installation requiring neither configuration nor extra electrical power, and makes for an innovative and cost-effective PoE repeater that extends power and data for another 100 meters. Extend your network for a PD (Powered Device) such as WLAN access points, network cameras, IP phones and others, with Gigabit high-speed for greater deployment flexibility. The GP-101ET Extender can be connected to any IEEE 802.3at/af end-nodes such as WLAN access points, network cameras, Voice over IP (VoIP) telephones and IP-based appliances where the IEEE 802.3at/af in-line Power over Ethernet port is supported. Enables the Ethernet cable to carry both data and power beyond the 100 meters limitation for ano…
    156,95
    Edimax GP-101IT Netwerk Poe Injector Gigabit
    Edimax GP-101IT Netwerk Poe Injector Gigabit
    The Edimax GP-101IT is a Power over Ethernet injector that not only delivers a cost-effective solution for power distribution, but also provides a seamless way of deployment on the existing LAN infrastructure. With the use of power injectors, DC power of up to 30W and the data that comes from a non-PoE switch or router are merged together and then transmitted to the IEEE 802.3at/af compliant products such as PoE dome cameras through the Ethernet cabling. Hence, preserving your investment in hardware upgrade without the need for buying extra PoE switches.Because of adding the capability of IEEE 802.3at/af Power over Ethernet to a non-PoE Ethernet switch or router, the GP-101IT can directly be connected to any IEEE 802.3at/af end-nodes such as PTZ (Pan, Tilt, Zoom) network cameras, PTZ speed dome, color touch-screen Voice over IP (VoIP) telephones and multi-channel wireless LAN access points where the IEEE 802.3at/af in-line Power over Ethernet port is supported.The Power over Ethernet t…
    73,95

    Klanten-reviews van Level One GEP-0821

    Er zijn nog geen beoordelingen voor dit productBen jij de eerste die een review plaatst?

    Meer over Level One GEP-0821

    Productomschrijving

    - Complies with IEEE 802.3af, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab and IEEE 802.3x
    - 8 PoE ports support 15.4W power to PoE Powered Device
    - Provide safe and reliable power to WLAN Access Points or Network Cameras
    - Auto-detection and protection of non-standard Ethernet Terminals
    - Supports 10/100/1000Mbps Base-T applications
    - Auto-MDI/MDI-X detection on each RJ-45 port
    - Internal power supply
    - Compact design fits easily in WLAN Access
    - Total PoE power budget: 123.2W

    Product Overview
    The LevelOne GEP-0821 is a high-performance 10/100/1000Mbps Gigabit Ethernet PoE Switch. Each PoE Port is powered up to 15.4W. The total PoE power budget is 123.2W. The switch automatically detects IEEE802.3af compliant powered devices and provides power and data over a single cable. Its an ideal solution for office and home users to utilize a combination of PoE and non-PoE devices.

    Advance Switching with PoE Function
    The GEP-0821 offers advance switching and provide power to network devices using Ethernet cables. This scalable and cost effective solution allows a managed network to efficiently expand to previously unattainable levels. The GEP-0821 offers the PoE technology conveniently eliminates the need to install networked devices, such as IP cameras and access points, near a power outlet, thereby reducing
    equipment and installation costs.

    Stable and reliable network Environment
    GEP-0821 enables users to deploy a stable and reliable high-speed LAN environment, with store-and-forward switching architecture, the GEP-0821 provide a stable and reliable packet error filtering and non-blocking packet forwarding architecture.

    Easy to use
    The GEP-0821 provides rack-mount and desktop options giving users their choice of deployment location. It is ideal for small business and workgroup requiring to deploy the PoE for the wireless access points, IP-based surveillance camera or IP phones in any places easily, efficinetly and cost effective. For instant error detection, the GEP-0821 is equipped with LED Indicators to define problems on the network.
    - EAN: 4015867163849
    - Vendorcode: 0520825

    Productspecificaties

    Artikelnummer(s)
    EAN
    4015867163849
    Brand
    LevelOne
    Poorten & interfaces
    Aantal basis-switching RJ-45 Ethernet-poorten
    8
    Type basis-switching RJ-45 Ethernet-poorten
    Gigabit Ethernet (10/100/1000)
    Netstekker
    DC-in ingang
    Netwerk
    Netwerkstandaard
    IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
    Koperen ethernetbekabelingstechnologie
    10BASE-T, 100BASE-TX, 1000BASE-TX
    Ondersteundende kabel types
    Cat5, Cat6, Cat7
    Full duplex
    Ja
    Datastroombeheer
    Ja
    Data-uitwisseling
    Switchingcapaciteit
    16 Gbit/s
    MAC-adrestabel
    8192 entries
    Store-and-forward
    Ja
    Jumbo Frames ondersteuning
    Ja
    Jumbo frames
    9000
    Packet forwarding rate (1 Gbps)
    1488000 pps
    Packet forwarding rate (100 Mbps)
    148000 pps
    Packet forwarding rate (10 Mbps)
    14880 pps
    Design
    Rack-montage
    Ja
    Kleur van het product
    Grijs
    LED-indicatoren
    Activiteit, Power over Ethernet (PoE)
    Land van herkomst
    Taiwan
    Certificering
    FCC, CE
    Prestatie
    Buffergrootte
    128 KB
    Energie
    AC-ingangsspanning
    100 - 240 V
    AC-ingangsfrequentie
    50 - 60 Hz
    Stroom
    2 A
    Stroomverbruik (typisch)
    130 W
    Power over Ethernet (PoE)
    Power over Ethernet (PoE)
    Ja
    Aantal Power over Ethernet plus (PoE +)-poorten
    8
    Totaal Power over Ethernet (PoE)-budget
    123,3 W
    Eisen aan de omgeving
    Bedrijfstemperatuur (T-T)
    0 - 45 °C
    Temperatuur bij opslag
    -40 - 70 °C
    Relatieve vochtigheid in bedrijf (V-V)
    10 - 90 procent
    Luchtvochtigheid bij opslag
    10 - 90 procent
    Gewicht en omvang
    Breedte
    280 mm
    Diepte
    185 mm
    Hoogte
    44 mm
    Gewicht
    2 kg
    Verpakking
    Meegeleverde kabels
    AC
    Snelstartgids
    Ja
    Type verpakking
    Doos
    Breedte verpakking
    371 mm
    Diepte verpakking
    230 mm
    Hoogte verpakking
    82 mm
    Gewicht verpakking
    2,26 kg
    Logistieke gegevens
    Code geharmoniseerd systeem (HS)
    85176990
