UK 6 N - Feed-through terminal block 8,2mm 41A UK 6 N
EAN: 4017918090821 - manufacturer-number: UK6N - Feed-through terminal block 8,2mm 41A Connectable conductor cross section fine-strand without cable end sleeve 0,2 ... 6mm², Connectable conductor cross section fine-strand with cable end sleeve 0,25 ... 6mm², Connectable conductor cross section solid-core 0,2 ... 6mm², Connectable conductor cross section multi-wired 0,2 ... 6mm², Rated current In 41A, Rated voltage 800V, Type of electrical connection 1 Screw connection, Type of electrical connection 2 Screw connection, Connection position Sideways, Number of levels 1, Number of clamp positions per level 2, Mounting method DIN rail (top hat rail) 35 mm, Material insulation body Thermoplastic, Inflammability class of insulation material acc. with UL94 V0, Width/grid dimension 8,2mm, Height at lowest possible mounting height 47mm, Length 42,5mm, Explosion-tested version Ex e, Closing plate required, Colour Grey - UK 6 N
