BLOCK AND BLOCK SIGMA-50 Truss Lifter 120kg 5mHigh-quality truss lift for loads up to 120 kg, made in EUThree-part telescopic ground supportSafety bolts to lock the different sections at different heightsLocking bolts in the base area to lock the boomsBooms with adjustable spindle and steel plate with non-slip rubber baseCorrosion protection through epoxy coatingWater level to ensure a vertical positionEarthing connectionTransport rolls to move the lift when retractedAL-KO 351 PLUS winch: Maximum load 350 kg with automatic holding brake. CE declaration of conformity in compliance with the harmonized standards DIN EN 13157, EN 12100 I and II, EC Machinery Directive 2006/42/CEGalvanized steel ropes 6x19+1, manufactured in compliance with the standard 13414-1:2004, tensile strength 1770N/mm2Material: Carbon steel S-275-J0H, manufactured in compliance with the standards EN10219 and EN10305.5Adjustable heightMade in EuropeWith BGV-C1 test certificateMaximum carrying capacity:120 kgMinimum load:25 kgNominal tensile strenght of rope:1770…1.436,25
BLOCK AND BLOCK OMEGA-50 Truss lifter 200kg 6.25mHigh-quality truss lift for loads up to 200 kg, made in EUFive-part telescopic ground supportSafety bolts to lock the different sections at different heightsLocking bolts in the base area to lock the boomsBooms with adjustable spindle and steel plate with non-slip rubber baseCorrosion protection through epoxy coatingWater level to ensure a vertical positionEarthing connectionTransport rolls to move the lift when retractedAL-KO COMPAC 900 winch: Maximum load 900 kg with automatic holding brake. CE declaration of conformity in compliance with the harmonized standards DIN EN 13157, EN 12100 I and II, EC Machinery Directive 2006/42/CEGalvanized steel ropes 6x19+1, manufactured in compliance with the standard 13414-1:2004, tensile strength 1770N/mm2Material: Carbon steel S-275-J0H, manufactured in compliance with the standards EN10219 and EN10305.5Adjustable heightWith BGV-C1 test certificateMaximum carrying capacity:200 kgMinimum load:25 kgHeight:Maximum: 625 cm above 5 sectionsMinimum: 15…3.998,75
BLOCK AND BLOCK DELTA-60 Winch Stand 120kg 3.3mHigh-quality winch stand for low-weight loads, made in EUAdjustable heightWith BGV-C1 test certificateMinimum load:25 kgMaximum load:120 kgHeight:Maximum: 330 cmMinimum: 134 cmAttachment system:Ã 35mmType (general stands):Light stand/wind upMaterial:Steel (powder-coated)Color:BlackWeight:20,50 kg1.186,25
BLOCK AND BLOCK GAMMA-50 Truss lifter 300kg 6.2mHigh-quality truss lift for loads up to 300 kg, made in EUFive-part telescopic ground supportSafety bolts to lock the different sections at different heightsLocking bolts in the base area to lock the boomsBooms with adjustable spindle and steel plate with non-slip rubber baseCorrosion protection through epoxy coatingWater level to ensure a vertical positionEarthing connectionTransport rolls to move the lift when retractedAL-KO COMPAC 900 winch: Maximum load 900 kg with automatic holding brake. CE declaration of conformity in compliance with the harmonized standards DIN EN 13157, EN 12100 I and II, EC Machinery Directive 2006/42/CEGalvanized steel ropes 6x19+1, manufactured in compliance with the standard 13414-1:2004, tensile strength 1770N/mm2Material: Carbon steel S-275-J0H, manufactured in compliance with the standards EN10219 and EN10305.5Adjustable heightMade in EuropeWith BGV-C1 test certificateMaximum carrying capacity:300 kgMinimum load:40 kgNominal tensile strenght of rope:177…5.123,75
BLOCK AND BLOCK DELTA-100 Winch Stand 150kg 4.8mHigh-quality winch stand for low-weight loads, made in EUAdjustable heightWith BGV-C1 test certificateMinimum load:25 kgMaximum load:150 kgHeight:Maximum: 480 cm above 3 sectionsMinimum: 159 cmAttachment system:Ã 35mmType (general stands):Light stand/wind upMaterial:Steel (powder-coated)Weight:32,00 kg1.561,25
BLOCK AND BLOCK DELTA-40 Winch Stand 100kg 3mHigh-quality winch stand for low-weight loads, made in EUEasy handling1-gear winch for easy lifting of the loadsAutomatic braking systemSafety bolt for mechanical lockingAdjustable heightMade in EuropeWith BGV-C1 test certificateFor application areas such as: Mobile useMaximum carrying capacity:100 kgMinimum load:25 kgNominal tensile strenght of rope:1770 N/mm²Height:Maximum: 300 cmMinimum: 158 cmAttachment system:Tube: à 35mmSteel rope:à 3 mmType (general stands):Light stand/wind upMaterial:Steel (powder-coated)Base area:à 1,1 mDimensions:Width: 27 cmDepth: 18 cmHeight: 1,75 cmWeight:13,00 kg561,25
