Qubino Smart Meter
Qubino Zwave smart meter Verbruiksmeting, zichtbaar in je control station (Fibaro HCL3, HC2, Domoticz, Homey, etc).De perfecte Z-Wave Smart Energy Meter (1 fase).Het meet het energieverbruik van je netwerk.Rapporteert in W en kWh, V, A, var, kWh import, kWh export, kVAh en kvarh. Handleiding Main terminals (LI, NI, Lo, No) Contacts capacity: 1.5 ... 16 (25) mm2 Connection screws: M5 Max torque: 3.5 Nm (PZ2) Optional terminals (1,2,4,5) Contact capacity: 0.05 ... 1 (2.5) mm2 Screws: M3 Max torque: 0.6 Nm Measuring input: Type (connection): single phase (1b) Reference current (Iref): 5 A Maximum current (Imax): 65 A Minimum current (Imin): 0.25 A Starting current: 20 mA Voltage (Un): 230 V (±20%) Power consumption at Un: < 2 W Nominal frequency (fn): 50 and 60 Hz Accuracy: Active energy and power: Standard EN 62053-21: class 1 Standard EN 50470-3: class B Reactive energy: Standard EN 62053-23: class 2 Optical communication: …
111,-
